NV076LRF is a high-performance digital night vision scope developed by INFREDAR based on the NV075. It inherits NV075’s highly acclaimed modular design—users can swap objective lenses to achieve different magnification levels, meeting diverse distance requirements. It also features significant upgrades across multiple aspects.
Key Upgrades
Â
- Enhanced Sensor: 20% higher light sensitivity than the NV075
- New Integrated Tools: 1000m laser rangefinder + laser red dot for precision targeting
- Ballistic Calculator: Improves shooting accuracy significantly
- Reticle System Upgrade: 11 reticle options (up from 7) with zeroing magnification
- Standby Mode: Enables quick wake-up and extended battery life
- Added Usability Features: Picture-in-picture display and Wi-Fi connectivity
- High-Power IR Illuminator Upgrade: 5 brightness levels, boosting detection range to 450m in total darkness (compared to 200m of the NV075)
Â
Maintaining competitive pricing, the NV076LRF combines advanced functionality with proven reliability to boost your sales and customer satisfaction.
Â
For entry-level models with high cost performance, click here.
Key features
- Ultra-lightweight 500g compact design
- Integrated 1000m laser rangefinder
- laser red dot
- PIP Mode/ WiFi
- 1920×1080 high-sensitivity CMOS sensor
- Interchangeable 25mm/35mm/50mm lenses
- 940nm/850nm laser IR illumination (200m range)
- One-touch photo/video recording
- Modular “swap-and-repair” maintenance design
- Optimized cost structure for distributor profitability
| Model: NV076LRF-25 | 35 | 50 | |
| Detector | |
| Sensor Type | Low-light CMOS |
| Resolution (Pixels) | 1920X1080 |
| Frame Rate | 30Hz |
| DISPLAY | |
| Type | 1.2-inch Circle OLED |
| Resolution | 390x390 |
| Optical Performance | |
| Objective Lens | 25mm | 35mm | 50mm |
| Eyepiece Diameter | 38.5mm |
| Basic Magnification | x2.2 | x3.2 | x4.6 |
| Eye Relief | 40mm |
| Field of View | 15.5° | 10.6° | 7.4° |
| FEATURES | |
| Languages | 12 |
| Reticle Types | 11 |
| Reticle Colors | 4 |
| Magnification Zeroing and Calibration | Yes |
| Loop Recording | Yes |
| Photo/Video Capture | Yes |
| Playback | Yes |
| Exposure Compensation | Yes |
| Time Adjustment | Yes |
| Auto Shutdown | Yes |
| Sleep/Wake | Yes |
| WIFI | Yes |
| Picture-in-Picture (PIP) | Yes |
| Ranging (Up to 1000m at Night) | Yes |
| Automatic Ballistic Calculation | Yes |
| Type-C Charging | Yes |
| IR Illuminator Power | 8W |
| IR Illumination Levels | 5 |
| Digital Zoom | 3.5 |
| Display Colors | 5 |
| Laser Red Dot | Yes |
| Other | |
| SD Card | Supports up to 128GB |
| Protection Rating | IP54(Waterproof) |
| Battery Type | 18650 Rechargeable Lithium Battery |
| Battery Life | 2-8 hours |
| Material | Aluminum Alloy |
| Dimensions (mm) | 180*55*65 (excluding eyecup) |
| Weight (g) | 390 | 400 | 420 |
